Build and run a debug build

This page takes a fresh clone of the repository to a debug build running on a device. The app is offline by design: it needs no environment variables and talks to no server, so nothing here asks you for a key or an account.

Prerequisites

Tool	Version	Used for
Git	any recent	Cloning the repository
Node.js	20 or later	Metro, the tests and the scripts
npm	the one bundled with Node.js	Installing the locked dependency tree
Ruby and Bundler	3.2.2, as .ruby-version says	CocoaPods on iOS
Watchman	any recent	Faster file watching for Metro
Android Studio, with the SDK, the platform tools and a JDK 17 or later		Android builds
Xcode with its command line tools		iOS builds, macOS only

Check what you have:

node -v
npm -v
ruby -v
bundle -v

Clone and install

git clone https://github.com/Brainchip-Inc/BrainChip-Connect.git
cd BrainChip-Connect
npm ci

Note

package-lock.json is committed and npm is the only supported package manager. npm ci installs exactly the locked tree, and its postinstall step runs patch-package, which applies the repository’s patches to react-native-ble-plx and react-native-screens. Check the install log for react-native-ble-plx@3.5.0 ✔: on a version mismatch patch-package reports the failure but still exits successfully, so a drifted install silently ships without the Android fix. Use npm install only when you mean to change a dependency, and commit the updated lockfile with it.

Android

Set ANDROID_HOME and make sure adb is on your PATH. Start an emulator from Android Studio, or connect a phone with USB debugging on, and check that it is listed:

adb devices

Before your first development build, create android/app/src/debug/AndroidManifest.xml by hand. It is local-only and ignored by git, so a fresh checkout does not have it.

Caution

Without that file the app cannot reach the Metro dev server and stops on a red screen reading Unable to load script. The file only needs to declare the android.permission.INTERNET permission and set usesCleartextTraffic on its <application> element; a release build never includes it. “The app is offline by design” in AGENTS.md says exactly what the file must contain.

Start Metro in one terminal and the app in another:

npm start

npm run android

iOS

Install the native dependencies once, then run on the simulator:

cd ios
bundle install
bundle exec pod install
cd ..
npm run ios

A physical iPhone needs signing set up in Xcode: open ios/BrainChipConnect.xcworkspace, select the BrainChipConnect target, turn on Automatically manage signing under Signing & Capabilities and choose your team. Enable Developer Mode on the phone when it asks, and trust the developer certificate if prompted.

A debug APK that runs without Metro

A plain ./gradlew assembleDebug produces android/app/build/outputs/apk/debug/app-debug.apk, which still fetches its JavaScript from Metro at run time and red-screens with Unable to load script once the dev server is gone. To hand someone a debug build that runs with no cable and no laptop, use the script that bundles the JavaScript in first:

scripts/build-standalone-debug-apk.sh
adb install android/app/build/outputs/apk/debug/app-debug.apk

The generated bundle and image assets are ignored by git, so running the script leaves nothing to commit. “The custom recipe a sideloaded debug build needs” in AGENTS.md explains why a plain build cannot do this on its own.

When a build misbehaves

Symptom	Fix
EADDRINUSE: address already in use :::8081	Another Metro is running. Find it with lsof -nP -iTCP:8081 -sTCP:LISTEN, stop it, and run npm start again.
Changes not showing up	Stop Metro and restart it with npm start --reset-cache.
Signing for "BrainChipConnect" requires a development team	Choose your team under Signing & Capabilities in Xcode.
No Podfile found	Run bundle exec pod install inside ios/, not the repository root.
iOS build breaks after pulling or changing dependencies	Run bundle install, then bundle exec pod install in ios/. If that is not enough, delete ~/Library/Developer/Xcode/DerivedData and install the pods again.
Android build breaks after changes	cd android && ./gradlew clean && cd .., then npm run android.

A full clean, when nothing else helps:

rm -rf node_modules ios/Pods ios/Podfile.lock ~/Library/Developer/Xcode/DerivedData
npm ci
bundle install
cd ios && bundle exec pod install && cd ..

scripts/clean_generated_files.sh lists the generated files the repository ignores, and deletes them with --apply.
